C# 滑动验证码|拼图验证|SlideCaptcha


使用背景:

  关于滑动验证码的使用场所还是非常多的,如: 调取短信接口之前,和 注册请求之前 或者 频繁会调用的接口 都需要加这个拼图验证。这里先上一下效果图吧(心中无码,自然高清)。

  话不多说,开撸!

  C# 滑动验证码|拼图验证|SlideCaptcha

C# 滑动验证码|拼图验证|SlideCaptcha





实现分析:

  滑动验证码的逻辑也很简单。大概说一下:

  1,服务器生成主图+附图(从主图裁剪下来的不需要管y坐标)并且存储X坐标;

  2,前端传入本地X坐标到服务器。

  3,服务器进行计算存储X坐标和本地X坐标相差值;

  4,验证相差值是否在 0-2 之间,判断 true | false







后端代码:

      准备:



        增加SlideCaptcha文件夹,并且增加Captcha.cs   CaptchaModel.cs   Config.cs   ImgFormat.cs   4个文件。分别是:验证,验证实体,配置和图片生成类。代码如下:



Captcha.cs




CaptchaModel.cs

using System; using System.Collections.Generic; using System.Drawing; using System.Linq; using System.Text;  namespace SliderCaptcha.NET {     public class CaptchaModel     {         public int X { get; set; }         public int Y { get; set; }         public Image Background { get; set; }         public Image Slide { get; set; }     }     public class Captcha64Model     {         public int X { get; set; }         public int Y { get; set; }         public string Background { get; set; }         public string Slide { get; set; }     } }



Config.cs
using System;  namespace SliderCaptcha.NET {     public class Config     {         /// <summary>         /// 矩形宽         /// </summary>         public static int l = 42;         /// <summary>         /// 圆形半径         /// </summary>         public static int r = 9;         /// <summary>         /// 圆形直径         /// </summary>         public static int d = r * 2;         /// <summary>         /// 计算圆形与矩形交接三角形边         /// </summary>         public static int a = (int)(r * Math.Sin(Math.PI * (50 / 180f)));         public static int b = (int)(r * Math.Cos(Math.PI * (50 / 180f)));         public static int c = r - a;         /// <summary>         /// 滑块边框         /// </summary>         public static int blod = 2;         /// <summary>         /// 水印         /// </summary>         public static string watermarkText = "SC.NET";         /// <summary>         /// 是否显示水印         /// </summary>         public static bool showWatermark = true;      } }





ImgFormat.cs
using System; using System.Collections.Generic; using System.Drawing.Imaging;  namespace SliderCaptcha.NET {     public class ImgFormat     {          private static Dictionary<string, string> Formats = new Dictionary<string, string>() {                             {"b96b3caa-0728-11d3-9d7b-0000f81ef32e","MemoryBmp"},                             {"b96b3cab-0728-11d3-9d7b-0000f81ef32e","Bmp"},                             {"b96b3cac-0728-11d3-9d7b-0000f81ef32e","Emf"},                             {"b96b3cad-0728-11d3-9d7b-0000f81ef32e","Wmf"},                             {"b96b3cae-0728-11d3-9d7b-0000f81ef32e","Jpeg"},                             {"b96b3caf-0728-11d3-9d7b-0000f81ef32e","Png"},                             {"b96b3cb0-0728-11d3-9d7b-0000f81ef32e","Gif"},                             {"b96b3cb1-0728-11d3-9d7b-0000f81ef32e","Tiff"},                             {"b96b3cb2-0728-11d3-9d7b-0000f81ef32e","Exif"},                             {"b96b3cb5-0728-11d3-9d7b-0000f81ef32e","Icon"}         };          public static ImageFormat FormatFromGuid(ImageFormat format)         {             return FormatFromGuid(format.Guid);         }         public static ImageFormat FormatFromGuid(Guid guid)         {             return FormatFromGuid(guid.ToString());         }         public static ImageFormat FormatFromGuid(string guid)         {             if (Formats.ContainsKey(guid))             {                 string name = Formats[guid];                 ImageFormat format = null;                 switch (name)                 {                     case "MemoryBmp":                         format = ImageFormat.MemoryBmp;                         break;                     case "Bmp":                         format = ImageFormat.Bmp;                         break;                     case "Emf":                         format = ImageFormat.Emf;                         break;                     case "Wmf":                         format = ImageFormat.Wmf;                         break;                     case "Gif":                         format = ImageFormat.Gif;                         break;                     case "Jpeg":                         format = ImageFormat.Jpeg;                         break;                     case "Png":                         format = ImageFormat.Png;                         break;                     case "Tiff":                         format = ImageFormat.Tiff;                         break;                     case "Exif":                         format = ImageFormat.Exif;                         break;                     case "Icon":                         format = ImageFormat.Icon;                         break;                 }                 return format;             }             else             {                 return null;             }                      }            public static string NameFromGuid(ImageFormat format)         {             return NameFromGuid(format.Guid);         }         public static string NameFromGuid(Guid guid)         {             return NameFromGuid(guid.ToString());         }         public static string NameFromGuid(string guid)         {             if (Formats.ContainsKey(guid))             {                 return Formats[guid];             }             else             {                 return string.Empty;             }          }      } }





      使用:

        这里用的是asp.net mvc 的框架,用的是api接口,前后端分离供前端使用。具体使用根据个人需求,可以是接口调用亦可以是项目调用。

        呼声如果很高的话,考虑出一个winfrom版本的滑动验证码~(滑稽)

        [HttpGet]         public IHttpActionResult GetCaptcha()         {             Captcha64Model model = Captcha.GenerateBase64();             CacheHelper.Cache.SetCache("sliderX", model.X);             Hashtable ht = new Hashtable();             ht.Add("background", model.Background);             ht.Add("slider", model.Slide);             ht.Add("sliderXXXXX", model.X);             return Json(ht);         }          /// <summary>         /// 检查验证         /// </summary>         /// <param name="x"></param>         /// <returns></returns>         [HttpPost]         public IHttpActionResult CheckCaptcha([FromBody] int x = 0)         {             Hashtable hs = new Hashtable();             string Mess = "";             int Code = 0;             var session = CacheHelper.Cache.GetCache("sliderX");             if (session == null)             {                 Mess = "请刷新验证码";                 Code = 500;                 goto block;             }             string sliderXStr = session?.ToString();// as string             int sliderX = Convert.ToInt32(sliderXStr);             int difX = sliderX - x;             if (difX >= 0 - Config.blod && difX <= Config.blod)             {                 Mess = "success";                 Code = 0;             }             else             {                 session = null;                 Mess = "错误";                 Code = 500;             }         block:             hs.Add("Mess", Mess);             hs.Add("Code", Code);             return Json(hs);         }





前端代码:



<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.0 Transitional//EN"> <html> <head>     <title>Splide Captcha</title>     <style>         * {             -webkit-user-select: none;             -moz-user-select: none;             -ms-user-select: none;             user-select: none;         }          .sc-captcha {             width: 300px;             margin: 100px auto;         }          .sc_net_panel {             padding: 10px;         }              .sc_net_panel > div {                 position: relative;             }          .bg_slider {             position: absolute;             left: 0;             top: 0;         }          .bg_refresh {             position: absolute;             right: 5px;             top: 5px;             background: #808080;             color: #fff;             border-radius: 3px;             width: 16px;             line-height: 16px;             text-align: center;             cursor: pointer;         }          .sc_net_slider_icon {             position: absolute;             left: 0;             top: 0;             height: 37px;             text-align: center;             border-radius: 5px;             border: #808080 1px solid;             width: 37px;             line-height: 37px;             cursor: pointer;         }              .sc_net_slider_icon:hover {                 color: #fff;                 background: #1991fa;             }          .sc_net_slider_text {             position: absolute;             left: 0;             top: 0;             text-align: center;             width: 280px;             color: #45494c;             border: #808080 1px solid;             border-radius: 5px;             line-height: 35px;             height: 37px;             cursor: default;         }          .sc_net_slider_area {             position: absolute;             left: 0;             top: 0;             height: 37px;         }     </style>     <script src="E:porject碚煜ApiByzkApiScriptsjquery-3.4.1.js"></script>     <script src="E:porject碚煜ApiByzkApiScriptsjquery-3.4.1.min.js"></script>  </head> <body>     <div>         <div class="sc-captcha">             <div class="sc_net_panel">                 <div class="sc_net_bg">                     <div class="sc_net_bgimg">                     </div>                     <div class="bg_refresh" onclick="loadCaptcha()" title="刷新">↻</div>                 </div>             </div>             <div class="sc_net_panel">                 <div class="sc_net_slider">                     <div class="sc_net_slider_text">向右拖动滑块填充拼图</div>                     <div class="sc_net_slider_area"></div>                     <div class="sc_net_slider_icon">➞</div>                 </div>             </div>         </div>     </div>  </body>  <script>     loadCaptcha();     function loadCaptcha() {         $.ajax({             url: "http://192.168.1.216:5500/api/TestApi/GetCaptcha",             type: "Get",             dataType: "JSON",             success: function (json) {                 var bg = createCanvas(280, 155);                 bg.className = 'bg_img';                 bg_slider = createCanvas(62, 155);                 bg_slider.className = 'bg_slider';                 CanvasSetImage(bg, json.background);                 CanvasSetImage(bg_slider, json.slider);                 var doc = document.getElementsByClassName("sc_net_bgimg")[0];                 doc.innerHTML = "";                 doc.appendChild(bg);                 doc.appendChild(bg_slider);                  console.log(json.modelX);             }         })     }      function createCanvas(width, height) {         var canvas = document.createElement('canvas');         canvas.width = width;         canvas.height = height;         return canvas;     };       function CanvasSetImage(_canvas, base64) {          //获取2d画布对象         var ctx = _canvas.getContext("2d");         //创建图片标签         var _img = document.createElement("img");         //设置图片地址         _img.src = base64;          //ctx.fillRect(0, 0, _canvas.clientWidth, _canvas.clientHeight);         //ctx.fillStyle = 'rgba(255, 255, 255, 0)';         _img.onload = function () {             ctx.drawImage(_img, 0, 0);         }         /*           ctx.drawImage(_img, 10, 10);*/     }      function getByClassName0(className) {         return document.getElementsByClassName(className)[0];     };      var slider = getByClassName0("sc_net_slider_icon");     var text = getByClassName0("sc_net_slider_text");     var area = getByClassName0("sc_net_slider_area");     var bg_slider;      slider.addEventListener('mousedown', handleDragStart);     slider.addEventListener('touchstart', handleDragStart);     document.addEventListener('mousemove', handleDragMove);     document.addEventListener('touchmove', handleDragMove);     document.addEventListener('mouseup', handleDragEnd);     document.addEventListener('touchend', handleDragEnd);     document.addEventListener('mousedown', function () { return false; });     document.addEventListener('touchstart', function () { return false; });      var originX, originY, trail = [],         isMouseDown = false;      var isOk = false;      function handleDragStart(e) {         console.log("handleDragStart");         if (isOk) return;         originX = e.clientX || e.touches[0].clientX;         originY = e.clientY || e.touches[0].clientY;         isMouseDown = true;     };      function handleDragMove(e) {         if (!isMouseDown) return false;         var eventX = e.clientX || e.touches[0].clientX;         var eventY = e.clientY || e.touches[0].clientY;         var moveX = eventX - originX;         var moveY = eventY - originY;         if (moveX >= 0 && moveX <= 243) {             slider.style.left = moveX + "px";             bg_slider.style.left = moveX / 243 * 218 + "px";         }      };      function handleDragEnd(e) {         if (!isMouseDown)             return false         isMouseDown = false         var eventX = e.clientX || e.changedTouches[0].clientX         if (eventX == originX)             return false          //获取前端的x坐标;         var a = $(".bg_slider");         var localX = a[0].offsetLeft;           $.ajax({             url: "http://192.168.1.216:5500/api/TestApi/CheckCaptcha?x=" + localX,             type: "Post",             dataType: "JSON",             success: function (res) {                 alert(res.Mess);             }         })     }; </script> </html>

结语:

    到这里基本上就已经完成了,以上前端地址更换成自己的接口即可。正常业务 验证码是很频发的一个操作并且是多用户。所以缓存存储的时候也需要注意一下。最后有问题的话,可以评论区沟通。感谢观看!(这次很用心在写,能否上个推荐~)
